Recommended Applications:
1. Assists in achieving ideal sectioning
2. Supports an embedding station by the side
3. Becomes a simple embedding system when used with a wax dispenser
· Unique outer housing w/ ergonomic design, delivers safe & comfortable operations.
· Eco-Compressor refrigeration system ensures efficient freezing & long service time.
· Micro-processor temperature control brings with easy operation & great performance.
· Spacious cold plate holds up to 48 paraffin blocks at a time.
· Ideal instrument top, accommodates necessary accessories and tools.
· Constant temperature functions upon arriving at set points, realizes energy saving and paraffin block readiness.
· High quality aluminum alloy constructed, provides with great conductivity.
· Unique elevated edges eliminate unexpected water drainage, helps maintain clean work surface.
P/N | CP380-000 | |||||||
Model No. | CP380 | |||||||
Physical Size | 535mm×330mm×358mm | |||||||
Cold Plate Size | 270mm×250mm | |||||||
Cold Plate Capacity | 48 blocks | |||||||
Net Weight | 20kgs | |||||||
Voltage | AC 220V/110V±10%, 50Hz/60Hz | |||||||
Rating | 170W | |||||||
Temperature Range | -15°C~-2°C | |||||||
Time to rreach set temperature | ≤15mins | |||||||
Standard Setting | Main Unit×1, Power Cable×1, Manual Instruction×1 |
