Supplied for a wide range of use in all kinds of life science laboratories to sophisticated microscopy solutions, the LuxSET biological microscopes feature high reliability and ergonomic characters for education, clinical lab expectations and the most demanding research projects
· Superior imaging and observation delivered by high-end optical system
· Reasonable ergonomic design and stable integral structure ensures effective and comfortable operation
· Multiple attachments are optical, including camera, Epi-Fluorescent device, dark field condenser, phase contrast kit and etc.
· The LuxSET biological microscopes are automatically delivered in cartons unless there are any special requirements pre-communicated and agreed at
●Standard Setting ○Optional Setting
Model Number | XJ032 | XJ033 | ||||||
Viewing Head | 30° gemel binocular, Eypepiece tube can rotate 360°, interpupillary distance range: 50-75mm | ● | ○ | |||||
30° gemel trinocular, Eypepieces tube can rotate 360°, interpupillary distance range: 50-75mm, fixed spectroscopical ratio R.T=8:2 | ○ | ● | ||||||
Eyepiece | High eye point wide field eyepiece PL10X/20mm with adjustable diopter | ● | ● | |||||
Nosepiece | Reversed quadruple nosepiece | ● | ● | |||||
Objective | Plan achromatic objective 4X/0.10(infinity) | ● | ● | |||||
Plan achromatic objective 10X/0.25(infinity) | ● | ● | ||||||
Plan achromatic objective 40X/0.65(infinity) | ● | ● | ||||||
Plan achromatic objective 100X/1.25(infinity) | ● | ● | ||||||
Stage | 150mmX140mm mechanical stage,move range:50mm×76mm;precision:0.1mm [triangle rail] | ● | ● | |||||
Condenser | N.A.1.25 Koehler illuminatory condenser with socket for phase contrast and darkfield accessories | ● | ● | |||||
Focusing System | Low position coaxial focus system with upper limited and tension adjustment.100V-240V voltage,single 3W LED(preseting center),intensity adjustable | ● | ● | |||||
Other Accessories | Spanner M3 | ● | ● | |||||
Spanner m1.6 | ● | ● | ||||||
Packaging | Styrofoam | ● | ● | |||||
Carton | ● | ● |
